Eoslift 27” x 46” Scissor Lift Pallet Truck | 2200 lb Capacity | Model I10

\n

The Eoslift I10 Scissor Lift Pallet Truck is a heavy-duty industrial-grade manual pallet jack designed for lifting, transporting, and positioning loads efficiently in warehouses, workshops, and commercial environments. Built with German-engineered reinforced steel construction and precision robotic welding, this pallet truck delivers outstanding durability, performance, and reliability.

\n

Featuring a powerful hydraulic lifting system, ergonomic controls, and a 2200 lb load capacity, the Eoslift I10 combines the functionality of a pallet jack and lift table into one versatile material-handling solution.

\n

Key Features

\n

\n
• Heavy-duty industrial-grade construction
\n
• German-engineered reinforced steel frame
\n
• Precision robotic welding for enhanced durability
\n
• 2200 lb lifting capacity
\n
• Ergonomic A-handle design for comfortable operation
\n
• 3-position control handle system
\n
• Powder-coated finish for corrosion resistance
\n
• Single or double cast pump with durable valve cartridge
\n
• Overload bypass valve prevents lifting beyond rated capacity
\n
• Top-of-stroke bypass protection for hydraulic system safety
\n
• Control lever automatically returns to neutral position when released
\n
• Smooth polyurethane wheels with durable steel hubs
\n
• Ideal for warehouses, loading docks, workshops, and industrial applications
\n

\n

Specifications

\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n

Specification	Details
Model	I10
Rated Capacity	2200 lbs
Load Center	23.6 in.
Service Weight	286 lbs
Wheel Material	Polyurethane (PU)
Fork Spread	27 in.
Fork Length	46 in.
Fork Width	6.38 in.
Lowered Fork Height	3.3 in.
Raised Fork Height	31.5 in.
Lift Height	28.15 in.
Overall Length	59 in.
Ground Clearance	0.71 in.
Steering Angle	185°

\n

Wheel Specifications

\n

\n
• Load Wheel Size: Φ2.95 × 1.97 in.
\n
• Steering Wheel Size: Φ7.1 × 2 in.
\n

\n

Warranty

\n

\n
• 3-Year Limited Warranty
