| ne power | 24 hp | 17.9 kW | | | | | Engine model number | 44 EXi | | | | | Forward speed | 0-7 mph
0-11.3 km/h | | | | | Front caster tires | 11×6-5 | | | | | Drive tires | 20×10-8 | | | | | Seat back height | High back with optional armrests, 18 in.
46 cm | | | | | Width of cut | Accel Deep™ mower deck, 48 in.
122 cm
Accel Deep™ mower deck, 54 in.
137 cm | | | | | Mulching system | Optional MulchControl™ attachment | | | | | Warranty | 3 year or 200 hour bumper-to bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | | | | Key Specs | Power | 24 hp
17.9 kW | | | | | Model number | 44 EXi | | | | | Displacement | 44.2 cu in.
724 cc | | | | | Cylinders | V-twin | | | | | Lubrication | Full pressure with replaceable filter, capacity, 2 U.S. qt
1.9 L | | | | | Type | Overhead valve | | | | | Battery | 12 V
300 CCA | | | | | Choke/speed control | Single lever | | | | | Cooling method | Air | | | | | Fuel tank capacity | 3.0 U.S. gal.
11.4 L | | | | | Fuel gauge | Translucent tank | | | | Engine | Dual hydros | Hydro-Gear EZT-D with 1-in. (2.5-cm) axles | | | | Drive train | Forward speed | 0-7 mph
0-11.3 km/h | | | | | Reverse speed | 0-3.5 mph
0-5.6 km/h | | | | | Speed and direction control | Twin levers | | | | | Control adjustment | 3 height, 11 positions | | | | Travel speed | Frame | Heavy-duty 2.5-in. x 2-in. (6-cm x 5-cm) front, and 1.5-in. x 2-in. (4-cm x 5-cm) side tubing | | | | | Primer/paint | E-coat/powder | | | | | Front caster tires | 11×6-5 | | | | | Front caster bearings | Sealed ball bearings | | | | | Drive tires | 20×10-8 | | | | | Hour meter | Yes | | | | | Service interval decal | Yes | | | | | Storage compartment | Optional covered | | | | | Cup holder | Yes | | | | | Maximum towing capacity | 250 lb
113 kg | | | | Chassis | Seat back height | High back with optional armrests, 18 in.
46 cm | | | | | Fore-aft adjustment | 2.9 in.
7 cm | | | | | Seat suspension | Two springs | | | | Seat | Type | Foot lift | | | | | Mower cut height | 1.25-4.5 in.
3-11 cm | | | | | Cut height increments | 0.25 in.
0.64 cm | | | | | Preset cut height | Yes | | | | Lift system | Width of cut | Accel Deep™ mower deck, 48 in.
122 cm
Accel Deep™ mower deck, 54 in.
137 cm | | | | | Type | Side discharge | | | | | Mower deck material | 10 gauge
0.135 in.
3.4 mm | | | | | Mower drive system | V-belt | | | | Mower deck | Type | Electric, 105 lb-ft
142 Nm | | | | | Drive | V-belt | | | | PTO | Wheelbase | 49.4 in.
1255 mm | | | | | Overall length | 75.4 in.
1915 mm | | | | | Width without mower | 43.3 in.
1100 mm | | | | | Width with mower | 48A: 62.6 in.
1590 mm
54A: 68.5 in.
1740 mm | | | | | Width with mower (deflector raised for storage) | 48A: 52.8 in.
1340 mm
54A: 57.1 in.
1450 mm | | | | | Height | 42.5 in.
1080 mm | | | | | Weight | 48A: 594 lb
270 kg
54A: 605 lb
275 kg | | | | Dimensions | Rollover protective structure (ROPS) | No | | | | | Slope operating limit | 13 degrees; 10 degrees with Material Collection System | | | | | Operator presence system | Yes | | | | | Park brake interlock | Yes | | | | | Operator video | Yes, online | | | | Operation | Note 1 | Durable Accel Deep Mower Decks are forged from 10-gauge steel with double captured mower wheels | | | | | Note 2 | Easily change cut height from 1.25 to 4.5 in. (3 to 11 cm) using the foot lift and cutting height dial | | | | | Note 3 | Integrated park brake is automatically applied when steering levers are stowed outward | | | | | Warranty | 3 year or 200 hour bumper-to bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/TUWarranty for details.) | | | | Buyer’s notes | Mulching system | Optional MulchControl™ attachment | | | | | Rubber floor mat | Optional | | | | | Sun shade | Optional | | | | | Mounted sprayer | Not available | | | | | Protective cover | Optional | | | | | Light kit | Optional | | | | | Material collection system | Two-bag Power Flow MCS, 6.5 bu
229 L | | | | Optional attachments | Manufacturing location | Greeneville, Tennessee, USA | | | | | Date collected | 3-Oct-22 | |
